Features:
- Pocket-size & economically price
- Using the high speed microprocessor DSP;
- Using the OLED screen, bright and without visual angle
- Data output USB port
- Large measuring range suitable for most materials
- Measures flat, outer cylinder and sloping surface
- Both Ra and Rz parameters in one instrument
- Works on 3.7V rechargeable lithium-battery, work while charging
- Real time battery indicator
Technical Specifications:
|
Roughness parameter |
Ra,Rz,Rq,Rt |
|
Tracing length |
6mm |
|
Tracing speed |
1.0mm/sec |
|
Cut-off lengths |
0.25mm/0.8mm/2.5mm |
|
Evaluation length |
1.25mm/4.0mm |
|
Measuring range |
Ra: 0.05-10.0μm Rz: 0.1-50μm |
|
Accuracy |
±5% |
|
Repeatability |
<12% |
|
Radius and angle of the stylus point |
Diamond,Radius : 10μm±1μm Angle: 90°(+5°or -10°) |
|
Power supply |
3.7V Li-ion battery |
|
Recharging time |
3 hours |
|
Operating temperature |
-20-40 ℃ |
|
Relative humidity |
<90% |
|
Dimensions (L×W×H) |
106×70×24mm |
|
Weight |
200g |
Standard delivery:
Main unit
Specimen Ra
Charger & USB cable
Instruction manual
Carrying case
